ThinKom ThinPack Ku100i portable Ku-band flat-panel satcom antenna (6.5 lb, G/T 11.5 dB/K, 45 to 50 cm dish equivalent)
ThinKom
ThinKom ThinPack Ku100i portable Ku-band flat-panel satcom antenna (6.5 lb, G/T 11.5 dB/K, 45 to 50 cm dish equivalent)
Model: ThinPack Ku100i
Pricing for this product is provided on request.
Request a quoteThe ThinPack Ku100i is the lighter, higher-gain Ku-band variant in ThinKom's ThinPack portable antenna family, using the patented CTS flat-panel technology. It is network- and modem-agnostic, works with wide-beam and HTS Ku-band services and needs no assembly. ThinKom quotes up to 20 Mbps down and 10 Mbps up for the ThinPack range.
Specifications
| Band | Ku-band: Tx 13.75 to 14.5 GHz, Rx 10.7 to 12.75 GHz |
| G/T | 11.5 dB/K (at 12.25 GHz) |
| EIRP | 40 dBW (at 14.25 GHz with 6 W BUC) |
| Parabolic dish equivalent | 45 to 50 cm |
| Polarization | Linear (manually aligned) |
| Weight | 6.5 lb |
| Dimensions | 16.1 x 9.6 x 2.1 in (L x W x H) |
| Operating temperature | -40 °C to +60 °C |
| Throughput (ThinPack range) | Up to 20 Mbps down x 10 Mbps up |
| Environmental | MIL-STD-810 |
| Model | ThinPack Ku100i |
