Intellian VS60 65 cm ViaSat-3 Ka-band Maritime Terminal for NexusWave
Intellian
Intellian VS60 65 cm ViaSat-3 Ka-band Maritime Terminal for NexusWave
Model: VS60
Pricing for this product is provided on request.
Request a quoteThe VS60 is a 65 cm Ka-band maritime VSAT terminal designed for the ViaSat-3 GEO constellation and compatible with Inmarsat NexusWave. It integrates the modem and high-power transceiver in the antenna unit, uses single-cable MoCA 2.0 installation and AptusNX control.
Specifications
| Network | ViaSat-3 Ka-band (Inmarsat NexusWave) |
| Reflector diameter | 65 cm (25.6 in) |
| Radome dimensions | 86 cm (W) x 93 cm (H) / (33.9 in x 36.6 in) |
| System weight | ADU: < 43.0 kg (94.8 lbs) / BDU: 5.2 kg (11.5 lbs) |
| Frequency range | Rx: 17.70 – 21.20 GHz / Tx: 27.50 – 31.00 GHz (3.5GHz Wideband Ka) |
| EIRP | 54 dBW |
| G/T | Min. 14.5 dB/K @ 10° EL |
| Model | VS60 |
Need installation or a bulk quote? Talk to our team.
