Intellian OW130L 1.25 m Land Dual Parabolic Enterprise Terminal for Eutelsat OneWeb
Intellian
Intellian OW130L 1.25 m Land Dual Parabolic Enterprise Terminal for Eutelsat OneWeb
Model: OW130L
Pricing for this product is provided on request.
Request a quoteThe OW130L is a high-performance enterprise land user terminal for Eutelsat's OneWeb LEO constellation with two 125 cm reflectors and a minimum of 18.2 dB/K G/T. The pair of antennas keeps the link consistent during LEO satellite handovers.
Specifications
| Network | Eutelsat OneWeb (Ku-band LEO) |
| Reflector diameter | 125 cm (49.2 inches) |
| Radome dimensions | 150 cm x 143 cm (59.1 x 56.3 inches) |
| Antenna weight (primary) | 95 kg (209.4 lbs) | 96 kg (211.6 lbs) with heating module |
| Antenna weight (secondary) | 94 kg (207.2 lbs) | 95 kg (209.4 lbs) with heating module |
| TX frequency | 14 GHz ~ 14.5 GHz |
| RX frequency | 10.7 GHz ~ 12.7 GHz |
| TX gain | 42.5 dBi |
| RX gain | 40.8 dBi |
| G/T | 18.2 dB/K (@11.8 GHz) |
| Model | OW130L |
