Home / Shop / Satellite Communications / Comtech SLM-5650C2 ODU Outdoor Software Defined Satellite Modem (IP67, 950-2000 MHz L-band, up to 155.52 Mbps)
Comtech SLM-5650C2 ODU Outdoor Software Defined Satellite Modem (IP67, 950-2000 MHz L-band, up to 155.52 Mbps)
Comtech
Comtech SLM-5650C2 ODU Outdoor Software Defined Satellite Modem (IP67, 950-2000 MHz L-band, up to 155.52 Mbps)
Model: SLM-5650C2 ODU
Pricing for this product is provided on request.
Request a quoteThe SLM-5650C2 ODU is the outdoor, IP67-rated package of the SLM-5650C2 software defined modem, designed to meet MIL-STD-810G and to operate from -32 to 60 C. It has the same L-band waveform set as the indoor SLM-5650C2 and is aimed at government, military and small commercial SatCom terminals. It accepts 11-33 VDC or 100-240 VAC.
Specifications
| Type | Software defined satellite modem, outdoor unit (IP67) |
| Power | 11-33 VDC or 100-240 VAC, 53 W max |
| Dimensions | 2.8 x 6.0 x 8.0 in (134.4 cubic inches) |
| Weight | 6.0 lb (2.7 kg) |
| Operating temperature | -32 to 60 C |
| Ingress protection | IP67, designed to MIL-STD-810G |
| Frequency range | 950 to 2000 MHz L-band TX/RX, 1 kHz steps |
| Data rate | 8 kbps to 155.52 Mbps |
| Symbol rate | 32 ksps to 64 Msps |
| Modulation | BPSK, QPSK, OQPSK, 8PSK, 8QAM, 16QAM, 16APSK |
| FEC | Viterbi, Viterbi + Reed-Solomon, Trellis, Sequential, TPC, LDPC, EBEM Turbo (option), DVB-S2/S2X (option) |
| Data interface | 1 x Gigabit Ethernet (switch/bridge/routed) |
| Security | AES-256 TRANSEC (FIPS 140-3 module, NIST certification in process, per data sheet) |
| Model | SLM-5650C2 ODU |
Need installation or a bulk quote? Talk to our team.
