Comtech SLM-5650C2 Software Defined Satellite Modem (indoor, 950-2000 MHz L-band, up to 155.52 Mbps, 3.8 lb)
Comtech
Comtech SLM-5650C2 Software Defined Satellite Modem (indoor, 950-2000 MHz L-band, up to 155.52 Mbps, 3.8 lb)
Model: SLM-5650C2
Pricing for this product is provided on request.
Request a quoteThe SLM-5650C2 is a compact, conduction-cooled software defined satellite modem for government and military use and for small commercial SatCom terminals. It is certified for use over WGS, covers L-band 950 to 2000 MHz and adds a multi-core packet processor option for QoS and L2/L3 routing. The indoor unit weighs 3.8 lb and runs from 12 VDC.
Specifications
| Type | Software defined satellite modem, indoor unit (conduction cooled) |
| Power | 12 VDC, 40 W max load |
| Dimensions | 1.8 x 5.3 x 7.2 in (68.7 cubic inches) |
| Weight | 3.8 lb (1.7 kg) |
| Operating temperature | -10 to 70 C (depends on mounting rail temperature) |
| Frequency range | 950 to 2000 MHz L-band TX/RX, 1 kHz steps |
| Data rate | 8 kbps to 155.52 Mbps |
| Symbol rate | 32 ksps to 64 Msps |
| Modulation | BPSK, QPSK, OQPSK, 8PSK, 8QAM, 16QAM, 16APSK |
| FEC | Viterbi, Viterbi + Reed-Solomon, Trellis, Sequential, TPC, LDPC, EBEM Turbo (option), DVB-S2/S2X (option) |
| Data interface | 1 x Gigabit Ethernet (switch/bridge/routed) |
| Security | AES-256 TRANSEC (FIPS 140-3 module, NIST certification in process, per data sheet) |
| Model | SLM-5650C2 |
