Comtech CDM-760 Advanced High-Speed Trunking and Broadcast Modem (0.1 to 150 Msps, DVB-S2/S2X, over 720 Mbps simplex)
Comtech
Comtech CDM-760 Advanced High-Speed Trunking and Broadcast Modem (0.1 to 150 Msps, DVB-S2/S2X, over 720 Mbps simplex)
Model: CDM-760
Pricing for this product is provided on request.
Request a quoteThe CDM-760 is a high-speed trunking and broadcast modem that can be configured as a DVB-S2/S2X modulator, demodulator or full modem. It supports ACM and CCM, Comtech's DVB-S2 Efficiency Boost waveforms, Dynamic Pre-Distortion and DoubleTalk Carrier-in-Carrier, and works on HTS, GEO and MEO links. Comtech lists it for IP and telco trunking, DVB-S2/S2X video delivery and disaster-recovery links.
Specifications
| Type | High-speed satellite modem, 1RU rack mount |
| Symbol rate | 100 ksps to 150 Msps (simplex) |
| Data rate | 0.1 to more than 720 Mbps simplex; more than 1.4 Gbps duplex |
| IF frequency | Dual IF: 50-180 MHz (70/140 MHz) and 950-2150 MHz L-band |
| Modulation | QPSK, 8PSK, 16APSK, 32APSK, 64APSK, 128APSK, 256APSK (DVB-S2 EN 302 307, DVB-S2X EN 302 307-2, DVB-S2-EB1/EB2) |
| Data interfaces | 2 x 10/100/1000Base-T Ethernet standard; optional optical Gigabit Ethernet and PIIC cards (ASI, G.703 E3/T3/STS-1, STM-1, OC-3) |
| Management | HTTP, SNMP, Telnet, RS-232/485, in-band M&C over satellite |
| Power | 100-240 VAC, 50/60 Hz (43-60 VDC option); 88 W typical |
| Dimensions | 1RU, 1.75 x 19 x 18.65 in (4.4 x 48 x 47.4 cm) |
| Weight | 15 lb (6.8 kg) |
| Operating temperature | 0 to 50 C (32 to 122 F) |
| Model | CDM-760 |
