Mobile Gateway NEO C Ruggedised Satellite Router with PTT and VoIP for NEO Terminals
Cobham SATCOM
Mobile Gateway NEO C Ruggedised Satellite Router with PTT and VoIP for NEO Terminals
Model: Mobile Gateway NEO C
Pricing for this product is provided on request.
Request a quoteMobile Gateway NEO C is a ruggedised IP-based satellite router that turns a NEO terminal into a multi-user communication hub. It combines routing, Push-to-Talk and VoIP optimised for satellite links, with Ethernet and PoE ports and a WLAN access point. It works with the IP NEO C, Voyager NEO and Orion NEO terminals.
Specifications
| Dimensions (H/D/W) | 65 / 166 / 326 mm |
| Weight | 2.7 kg |
| Power input | 12 or 24 VDC, or PoE (802.3bt Type 3 Class 6) |
| Power consumption | Max. 172 W with all outputs loaded |
| Environmental protection | IP55 |
| Operating temperature | -21°C to +55°C |
| Ethernet ports | 5 (2 x PoE 802.3at output, 2 x standard LAN, 1 x PoE 802.3bt to the satellite terminal) |
| Other interfaces | WLAN 802.11 b/g/n/ac, USB 3.0, RJ11 phone, D-Sub 9 serial, 4-pin I/O (E&M) |
| Security | 256-bit AES encryption |
| Model | Mobile Gateway NEO C |
