C-COM iNetVu Ka-1200+G 1.2 m auto-deploy Ka-band driveaway VSAT antenna (GD 1.2 m antenna, Eutelsat and Intelsat compliant)
C-COM
C-COM iNetVu Ka-1200+G 1.2 m auto-deploy Ka-band driveaway VSAT antenna (GD 1.2 m antenna, Eutelsat and Intelsat compliant)
Model: iNetVu Ka-1200+G Driveaway
Pricing for this product is provided on request.
Request a quoteThe iNetVu Ka-1200+G is a 1.2 m auto-deploy Ka-band driveaway VSAT terminal for vehicle roofs. It supports the GD 1.2 m antenna (models 1132/3122), is compliant with Eutelsat and Intelsat and offers a 2-port Ka-band feed option. A one-button controller acquires a Ka-band satellite within 2 minutes (under 3 minutes with beacon receiver).
Specifications
| Band | Ka-band, receive 17.0 to 22.2 GHz (circular receive-only option); 2-port feed option |
| Compatibility | GD 1.2 m antenna (models 1132/3122); Eutelsat and Intelsat compliant |
| Reflector | 1.2 m offset, prime focus, thermoset-molded (carbon fibre optional) |
| Controller | iNetVu 7715 |
| Stowed dimensions | L 204.4 x W 124 x H 41.2 cm (80.5 x 48.8 x 16.2 in) |
| Shipping weight | 162 kg (356 lb) total: platform crate 140 kg plus reflector crate 22 kg |
| Azimuth | ±200° |
| Elevation | 0° to 90° |
| Deploy speed | Elevation 2°/s, azimuth 6°/s; peaking 0.2°/s |
| Motors | 24 VDC, 10 A max |
| Operating wind | 75 km/h (46.5 mph) |
| Survival wind | 112 km/h (70 mph) deployed; 225 km/h (140 mph) stowed |
| Operating temperature | -30 °C to +55 °C |
| Survival temperature | -40 °C to +65 °C |
| Model | iNetVu Ka-1200+G Driveaway |
