RG-S6120-48XMG4VS2QXS-UP-H 48-Port 10GE Managed Multi-GE Access Switches with 40GE Uplink Ports
Model: RG-S6120-48XMG4VS2QXS-UP-H
Pricing for this product is provided on request.
Request a quote48-Port 10GE Managed Multi-GE Access Switches with 40GE Uplink Ports. 10G/5G/2.5G/1G/100M access, PoE/PoE+/PoE++, 4 x 25G and 2 x 40G uplink optical ports, offering flexible networking options to build high-performance campus networks. 48 x 100/1000/2.5G/5G/10GBASE-T ports and 4 x 25GE and 2 x 40GE uplink ports are provided to realize flexible networking.
Specifications
| Fixed service port | 48 x 100/1000/2.5G/5G/10GBASE-T ports; Ports 1 to 24 support PoE/PoE+/PoE++; Ports 25 to 48 support PoE/PoE+; 4 x 10GE/25GE SFP28 ports; 2 x 40GE QSFP+ ports |
| Fixed management port | 1 x RJ45 console port; 1 x RJ45 MGMT port |
| System switching capacity | 1320 Gbps |
| System packet forwarding rate | 982 Mpps |
| PoE port | Ports 1 to 24 support PoE/PoE+/PoE++ (IEEE802.3af/at/bt) power supply |
| Power module | RG-PA600I-P-F; RG-PA1000I-P-F |
| Maximum power consumption | 90 W (without PoE); 460 W (full PoE load) |
| Unit dimensions (W x D x H) | 442.0 mm x 420.0 mm x 43.6 mm (17.40 in. x 16.54 in. x 1.72 in.) |
| Unit weight | 6.18 kg (13.62 lbs, with 3 fan modules) |
| Rack height | 1 RU |
| Operating temperature | 0°C to 45°C (32°F to 113°F) |
| Operating humidity | 10% to 90% RH (non-condensing) |
| Mean time between failure (MTBF) | 236,695 hours (about 27 years) |
| Model | RG-S6120-48XMG4VS2QXS-UP-H |
