Ruijie
RG-N18018-X Data Center Modular Core Switch with 16 Line Card Slots
Model: RG-N18018-X
Pricing for this product is provided on request.
Request a quoteData Center Modular Core Switch with 16 Line Card Slots. Fit for the core or aggregation node of a legacy data center or core node of a cloud data center, enabling smooth evolution to 400GE in future. Up to 768 x 100GE ports, 576 x 40GE ports, and 2304 x 10GE ports for line-rate forwarding. Ultra-large distributed buffer design, 200 ms buffering per port, and 24 GB buffer per card, ensuring zero packet loss upon traffic burst.
Specifications
| Switching capacity | 307.2 Tbps |
| Packet forwarding rate | 69,120 Mpps |
| Module slots | 2 x supervisor module slots; 16 x line card slots; 6 x switch fabric module slots; 16 x power module slots; 3 x fan module slots |
| Dimensions (W x D x H) | 442 mm x 961 mm x 934.5 mm (17.40 in. x 37.83 in. x 36.79 in.), without the cable management bracket; 442 mm x 1017 mm x 934.5 mm (17.40 in. x 40.04 in. x 36.79 in.), with the cable management bracket. |
| Operating temperature | 0ºC to 40ºC (32ºF to 104ºF) |
| Operating humidity | 10% to 90% RH (non-condensing) |
| Unit weight | 120.88 kg (266.49 lbs., a chassis with three fan modules) |
| Rack height | 21 RU |
| Model | RG-N18018-X |
