Ruijie
RG-IS5200-8GT4XS-UP-DC Industrial Ethernet Switch
Model: RG-IS5200-8GT4XS-UP-DC
Pricing for this product is provided on request.
Request a quoteIndustrial Ethernet Switch. Recommended for outdoor surveillance, special weather conditions, and manufacturing scenarios, meeting demands of complex environments, such as operation in high and low temperatures, vibration resistance, and surge protection. This next-generation Gigabit Industrial Ethernet switch is engineered for high resilience, reliability, and performance in demanding industrial environments.
Specifications
| Fixed service port | 8 x 10/100/1000BASE-T ports, supporting PoE/PoE+/PoE++; 4 x 1GE/10GE SFP+ ports |
| Packet forwarding rate | 72 Mpps |
| Switching capacity | 96 Gbps |
| Power supply | IPA240-P: 240 W (56 V/4.4 A) or external DC power supply |
| Fan | Fanless |
| Operating temperature | Installed in an enclosed cabinet: –40°C to +60°C; Installed in a ventilated cabinet: –40°C to +70°C; Installed in a fan-equipped cabinet : –40°C to +75°C |
| IP rating | IP41 by default (supporting upgrade to IP55) |
| Unit dimensions (W x D x H) | 150 mm x 133 mm x 86 mm (5.91 in. x 5.24 in. x 3.39 in.) |
| Unit weight | 1.53 kg (3.37 lbs) |
| Installation method | Desktop mounting, DIN rail mounting, and wall mounting |
| Fixed management port | 1 x RJ45 console port |
| PoE port | Ports 1 to 8 support PoE/PoE+/PoE++ (IEEE802.3af/at/bt) power supply |
| Maximum power consumption | 23.8W (Without PoE); 503.8W (full PoE load) |
| Operating humidity | 5% to 95% RH, Non-condensing |
| Mean time between failures (MTBF) | Below 40°C (104°F): at least 300,000 hours (about 34 years) |
| Model | RG-IS5200-8GT4XS-UP-DC |
Need installation or a bulk quote? Talk to our team.
