RG-CS86-20XS4VS2QXS-D 20-Port 10/2.5GE(SFP+), Layer 3 Ruijie Core/Aggregation Switch with Cloud Management, 4-Port 25/10GE(SFP28), 2-Port 40GE
Ruijie
RG-CS86-20XS4VS2QXS-D 20-Port 10/2.5GE(SFP+), Layer 3 Ruijie Core/Aggregation Switch with Cloud Management, 4-Port 25/10GE(SFP28), 2-Port 40GE
Model: RG-CS86-20XS4VS2QXS-D
Pricing for this product is provided on request.
Request a quote20-Port 10/2.5GE(SFP+), Layer 3 Ruijie Core/Aggregation Switch with Cloud Management, 4-Port 25/10GE(SFP28), 2-Port 40GE. Suitable for small & medium enterprise core, or large-scale campus network aggregation switch.
Specifications
| Fixed service port | 20 x 1GE/2.5GE/10GE SFP+ ports; 4 x 10GE/25GE SFP28 ports; 2 x 40GE QSFP+ ports; Note: One switch provides a maximum of 32 x 10GE ports. |
| Fixed management port | 1 x RJ45 console port; 1 x RJ45 MGMT port |
| Switching capacity | 760 Gbps |
| Packet forwarding rate | 570 Mpps |
| Power module | RG-PA150IB-F |
| Maximum power consumption | 85 W |
| Unit dimensions (W x D x H) | 440 mm x 330 mm x 43.6 mm (17.32 in. x 12.99 in. x 1.72 in.) |
| Unit weight | 4.6 kg (10.14 lbs) (empty chassis with 2 fan modules) |
| Rack height | 1 RU |
| Operating temperature | 0°C to 50°C (32°F to 122°F) |
| Operating humidity | 10% to 90% RH (non-condensing) |
| Mean time between failure (MTBF) | 200,000 hours (about 22 years) |
| Model | RG-CS86-20XS4VS2QXS-D |
