Ruijie
RG-CS85-48SFP4XS-D 48-Port 1GE SFP Layer 3 Enterprise-Class Core or Aggregation Switch, 4-Port 10GE Uplink
Model: RG-CS85-48SFP4XS-D
Pricing for this product is provided on request.
Request a quote48-Port 1GE SFP Layer 3 Enterprise-Class Core or Aggregation Switch, 4-Port 10GE Uplink. Aggregation switch for large-sized networks, or core switch for small and medium-sized networks. Aggregation switch for small and medium-sized campus networks, with four 10G uplink optical ports for high-speed data transmission; 48 x 1GE SFP ports, providing high-speed network experience for long-distance services.
Specifications
| Service port | 48 x 1GE SFP ports; 4 x 1GE/10GE SFP+ ports |
| Management port | 1 x console, 1 x MGMT, 1 x USB3.0 |
| Switching Capacity | 656 Gbps |
| Forwarding rate | 488 Mpps |
| Cooling mode | Fan cooling |
| Power Consumption | <150 W |
| Link Aggregation | Supported |
| Dimensions (W x D x H) | 442 x 420 x 43.6 mm (17.40 x 16.54 x 1.72 in), 1 RU |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Warranty period | 3 years |
| PoE port | All RJ45 ports support PoE/PoE+ (IEEE802.3af/at) power supply |
| Power module | RG-PA150IB-F |
| Unit weight | 5.3 kg; (11.68 lbs) |
| Rack height | 1 RU |
| Operating humidity | 10% to 90% RH (non-condensing) |
| Mean time between failure (MTBF) | 788,000 hours (about 90 years) |
| Model | RG-CS85-48SFP4XS-D |
Need installation or a bulk quote? Talk to our team.
