Ruijie
RG-CS83-48GT4XS-PD 48-Port 1GE RJ45 Layer 3 Managed Access Switch with PoE+, 4-Port 10GE Uplink
Model: RG-CS83-48GT4XS-PD
Pricing for this product is provided on request.
Request a quote48-Port 1GE RJ45 Layer 3 Managed Access Switch with PoE+, 4-Port 10GE Uplink. GE Access and PoE+ for Large-sized Networks. CPU Protect Policy (CPP) is supported to control the packet type and traffic volume sent to the CPU to prevent high CPU usage.
Specifications
| Service port | 48 x 10/100/1000BASE-T ports, supporting PoE/PoE+; 4 x 1GE/10GE SFP+ ports |
| Switching Capacity | 176 Gbps |
| Forwarding rate | 131 Mpps |
| Cooling mode | fan modules |
| AC | 200–240 VAC,50/60 Hz |
| Power Consumption | ≤ 55 W (non-PoE), or < 1570 W (PoE fully loaded) |
| Surge protection | 10 KV |
| Dimensions (W x D x H) | 442 mm x 420 mm x 43.6 mm |
| Operating Temperature | 0–45°C |
| Warranty period | 3 years |
| PoE | supported |
| Fixed management ports | 1 x RJ45 console port; 1 x RJ45 MGMT port |
| Unit weight | 4.6 kg (10.14 lbs) |
| Rack height | 1 RU |
| Operating humidity | 10% to 90% RH (non-condensing) |
| Mean time between failure (MTBF) | 315,000 hours (about 36 years, dual power modules); 193,000 hours (about 22 years, single power module) |
| Model | RG-CS83-48GT4XS-PD |
