Ruijie
RG-CS83-24GT4XS-PD 24-Port 1GE RJ45 Layer 3 Managed Access Switch with PoE+, 4-Port 10GE Uplink
Model: RG-CS83-24GT4XS-PD
Pricing for this product is provided on request.
Request a quote24-Port 1GE RJ45 Layer 3 Managed Access Switch with PoE+, 4-Port 10GE Uplink. GE Access and PoE+ for Large-sized Networks. CPU Protect Policy (CPP) is supported to control the packet type and traffic volume sent to the CPU to prevent high CPU usage.
Specifications
| Fixed service port | 24 x 10/100/1000BASE-T ports, supporting PoE/PoE+; 4 x 1GE/10GE SFP+ ports |
| Fixed management ports | 1 x RJ45 console port; 1 x RJ45 MGMT port |
| Switching capacity | 128 Gbps |
| Packet forwarding rate | 96 Mpps |
| PoE port | All RJ45 ports support PoE/PoE+ (IEEE802.3af/at) power supply |
| Power module | RG-PA600I-P-F; RG-PA1000I-P-F |
| Maximum power consumption | 65 W (non-PoE); 810 W (full PoE load) |
| Unit dimensions (W x D x H) | 442 mm x 420 mm x 43.6 mm (17.40 in.x 16.54 in.x 1.72 in.) |
| Unit weight | 4.3 kg (9.48 lbs) |
| Rack height | 1 RU |
| Operating temperature | 0°C to 45°C (32°F to 113°F) |
| Operating humidity | 10% to 90% RH (non-condensing) |
| Mean time between failure (MTBF) | 356,000 hours (about 41 years, dual power modules); 208,000 hours (about 24 years, single power module) |
| Model | RG-CS83-24GT4XS-PD |
Need installation or a bulk quote? Talk to our team.
