RG-RSR20-XA-36 36-Port Multi-service Fixed Access Router
Model: RG-RSR20-XA-36
Pricing for this product is provided on request.
Request a quote36-port multi-service fixed access router (WAN: 4 x 1GE ports + 4 x 1GE/10GE SFP ports; LAN: 24 x 1GE ports) recommended for access scenarios of small and medium-sized enterprise branches in financial, government and other industries. Integrates routing, switching, security and 4G/5G support in one device, with software and hardware dual redundancy and HQoS traffic management.
Specifications
| Fixed service port | WAN ports: 4 x 10GE SFP+ ports; 4 x 1GE SPF ports; 4 x 10/100/1000BASE-T ports; LAN ports (supporting LAN/WAN switching): 24 x 10/100/1000BASE-T ports |
| Fixed management port | 1 x RJ45 console port |
| Switching capacity | 224 Gbps |
| Packet forwarding rate | 4 Mpps |
| Unit dimensions (W x D x H) | 440 mm x 420 mm x 44 mm (17.32 inch. x 16.56 in. x 1.73 in.) |
| Operating temperature | 0°C to 50°C (32°F to 122°F) |
| Maximum power consumption | 150 W |
| Warranty duration | 3 years |
| USB | 1 x USB 2.0 port (Type-A connector) |
| Module slot | 4 x expansion module slots; 2 x power module slots |
| Number of IPv4 unicast routes | 100,000 |
| Number of IPv6 unicast routes | 100,000 |
| Rack height | 1 RU |
| Unit weight | < 7.8 kg (17.19 lbs, full configuration without packaging materials, with the nameplate at the bottom) |
| Power module redundancy | 1+1 redundancy |
| Model | RG-RSR20-XA-36 |
