Home / Shop / Wireless Networking / RG-AP820-L(V2) Wi-Fi 6 Dual-Radio 2.402 Gbps Indoor Access Point
RG-AP820-L(V2) Wi-Fi 6 Dual-Radio 2.402 Gbps Indoor Access Point
Ruijie
RG-AP820-L(V2) Wi-Fi 6 Dual-Radio 2.402 Gbps Indoor Access Point
Model: RG-AP820-L(V2)
Pricing for this product is provided on request.
Request a quoteThe RG-AP820-L(V2) is a Wi-Fi 6 dual-radio 2.402 Gbps indoor access point. Ideal for indoor scenarios including hotels, offices, retail stores, and schools. Key features: Upgraded to Wi-Fi 6, up to 2.402 Gbps data rate; Superior roaming experience and service continuity.
Specifications
| Wi-Fi standard | 802.11a/b/g/n/ac/ax |
| Radio design | Dual-radio: 2.4 GHz/5 GHz (2×2), 5 GHz (2×2);, up to 4 spatial streams |
| Max data rate | Combined peak data rate: 2.4 GHz + 5 GHz, 1.775 Gbps; 5 GHz + 5 GHz, 2.402 Gbps |
| Antenna | Integrated antenna design |
| Ports | 1 x 10/100/1000BASE-T port |
| Bluetooth | Bluetooth 5.0 |
| Power supply | 48 V DC/0.3 A power supply; PoE (802.3af) |
| Max power consumption | 12.95 W |
| External power supply | No |
| Operating temperature | –10°C to +50°C (14°F to 122°F) |
| Dimensions (W x D x H) | 153 mm x 193 mm x 26 mm (6.02 in. x 7.60 in. x 1.02 in.) |
| Mounting | Wall/Ceiling mounting |
| Warranty | 3 Years |
| Model | RG-AP820-L(V2) |
Need installation or a bulk quote? Talk to our team.
